The world market demands billions of scratch cards as calling cards, recharge vouchers for mobile phones and internet access cards. Besides standard cards with one scratch panel, more and more multi-voucher cards  are being introduced in order to compensate for the lower recharge values. New layouts are launched more and more frequently, requiring highly flexible machinery. The RADUSCARD for scratch cards with its unique retrofit concept provides future-proof investment in a flexible and modular machine. It allows entry configurations for start-ups as get-in business solutions as well as extended and specialized machine configurations. If changing markets require quick reactions, further modules are simply retrofit on demand. The convincing retrofit technology, the legendary durability, a well-established and simple machine operation, the unique data security concept and low maintenance requirements are making the RADUSCARD the first choice for emerging markets. Selection of devices: up to 4 inkjets  dedicated space for two scratch panel applicators installations  label / hot – for quick job interchange or customizing labels  hot / hot – for multi-panel cards or customizing scratch panels 1 or 2 cameras for data and scratch panel supervision  turn-over unit for frontside/backside imprints RADUSCARD – the superior get-in-business solution!
RadusCard

Database Print Personalization and Multiple

Scratch Panel Application

single cards ISO sized
SPECIFICATIONS
Functions / Features • Inkjet coding, single and multi-line – up to 4 inkjets • Scratch panel application by hot stamping and labeler • Multi-voucher cards – up to 4 scratch panels • Customized scratch panel generation • Verifying of imprints and scratch panels by camera system • Rejection of defective cards • Selection of reproduction mode inline, after main run and   on demand • Gapless event reporting by logfiles Main System RadusCard Controlling Microprocessor Operation Fully automatic Controll desk Display and Keyboard PC control WindowsTM Data encryption AES, 3DES, PGP etc. Card format ISO CR80: 85,6 mm x 54 mm Thickness 0,25 – 1,0 mm (10 – 40 mil) Material Cardboard, plastics such as PVC, ABS, etc. Magazine size 800 cards (0,5 mm) Performance  up to 12.000 cards/h with hot stamping unit up to 15.000 cards/h with labelling unit
Print system Continuous single-nozzle inkjet One to four print heads, each with own cabinet Inks MEK-inks, fast drying, non-pigmented Label Continuous Labeler (Plug-In unit) Roll size Roll Ø max. 12" (optional 360 mm), core 1.5" or 3" Label size Width up to 20 mm (optional 60 mm) Hotstamping Pneumatic (Plug-In unit), interchangeable dies Foil size max. 55 mm wide (optional 100 mm), 115 mm Ø Stamping width max. 50 mm (optional 90 mm) Camera CCD-cameras with adjustable aperture and focus Range coverage Adjustable from detailed to full card size, individually programmable fields for each camera OCR machine fonts Barcode all usual barcodes Scratch panel surface recognition, verification for presence etc. Illumination high frequency lighting Connections Compressed air 6 – 8 bar, oil free and dry Power supply single phase 220/240V, 50/60Hz, consumption max. 1kW Measures 2970 x 790 x 1510 mm (length x depth x height) Weight approx. 500kg, depending on configuration
Download Leaflet
